Drawing

The MCW series covers the electric self-braking worm gear winches. Developed for heavy duty pulling and traversing work up to 2000 kg , the MCW series has been a longstanding part of the Emcé winch programme. The MCW series is also available as a lifting winch with capacities up to 1700 kg. For more accurate positioning during pulling, or repetitive lifting jobs, an optional motor brake is available.

Standard features

• Self-braking wormgear transmission ¹⁾
• IP 54 400 V AC / 3 phases / 50 Hz non-braked motor
• Steel drum (not grooved) with cable fixing point at flange
• Single drum support (MCW 250, MCW 500)
• Two drum supports (all other models)
• Double layer 2-component conservation according ISO 12944 category C2-Low, colour RAL 5010
• FEM / ISO class: T2-L2-M2

¹⁾Braking action depends on gear ratio, and may require the addition of a motor brake.

Mechanical options

• Braked motor (aluminium or cast iron)
• IP 56 TENV cast iron motor for marine applications
• 220 single-phase motors (up to MCW 750)
• 24 V DC motors
• Explosion-proof motors
• Protective steel motor cover
• Manual or remotely controlled disengaging clutch
• Band brakes
• Grooved drum
• Drum pressure roller
• Alternative speeds
• Alternative drum dimensions / split drums / additional rope anchors / etc.
• Drum guards
• Emergency cranking
• Marine / offshore coating systems

Control options

• IP 65 direct pendant remote control with emergency stop (up to 1.5 kW 220 V AC / 1 phase or 2.2 kW 400 V AC / 3 phase)
• IP 55 Control box with push-buttons and emergency stop built acc. to NEN60204-32
• IP 66 Control box with low-voltage IP 65 remote control built acc. to NEN60204-32
• Load limiter
• Frequency inverter for variable speed control
• Wireless radio remote control systems
• Limit switches
• Slack wire switches
