medium |
Hydraulic |
|
environment |
Oil and Gas |
|
application |
Pulling |
|
series |
SH-series |
|
working Load Limit (WLL) [kg] |
2000 kg |
|
number of layers |
4 |
|
lifting WLL first layer |
2000 kg |
|
lifting WLL top layer |
1560 kg |
|
speed at first layer |
34 m/min |
|
drum capacity first layer |
11 m |
|
drum capacity top layer |
53 m |
|
rope diameter |
10 mm |
|
mass |
71 kg |
|
drain port BSP |
1/4” |
|
main port BSP |
1/2” |
|
pressure drop |
200 bar |
A range of standard hydraulic planetary winches, developed for heavy duty lifting and pulling applications of up to 10,000 kg were compactness is required. Due to the standard design, they can be supplied within short delivery times. All winches are fi tted with a brake as standard that makes them suitable for lifting applications.
Standard features
- Planetary transmission
- Orbit motor
- Steel drum (not grooved) with cable fixing point at flange
- Two drum supports
- Single layer of primer only, colour black
- Brake and single acting brake valve
Mechanical options
- Grooved drum
- Drum pressure roller
- Drum guards
- Marine / offshore coating systems
Control options
- Proportional control valves
- Hydraulic power packs
- Electric lower limit switch
- Load limiter
